1756-L72 controller module

1756-L72 controller module
Product Overview
1756-L72 is a ControlLogix series programmable automation controller (PAC) launched by Rockwell Automation/Allen Bradley in the United States. It is the core processing unit of the Logix5000 platform and is widely used in various industrial automation control scenarios.

📌 1756-L72S is its security version (GuardLogix) with built-in SIL 3 security functionality, which needs to be used in conjunction with the 1756-L7SP security module.

Model Interpretation
Meaning of field codes
1756- ControlLogix Series Identification
L-Logix controller (large high-performance)
72-4MB user memory+0.98MB I/O memory
S (optional suffix) – GuardLogix Safety Edition (SIL 3)
K (optional suffix) – Conformal Coating, suitable for harsh environments
Core technical parameters
Parameter specifications
Brand Allen Bradley (Rockwell Automation)
System ControlLogix/Logix5000 PAC
32-bit RISC processor
User Memory 4 MB (Standard)
I/O Memory 0.98 MB
No secure memory available (1756-L72S is 2MB secure memory)
Non volatile storage 1 GB SD card (1784-SD1, pre installed), expandable to 2 GB (1784-SD2)
communication interface ✅ Ethernet/IP (with built-in dual ports)
✅ ControlNet
✅ DeviceNet
✅ Data Highway Plus
✅ Remote I/O (1756 remote I/O link)
✅ SynchLink
✅ Third party network
Local communication 1 x full speed USB 2.0 port
Front panel 4-character alphanumeric display screen (status monitoring)
Working voltage 24VDC (nominal), range of 10~31.2VDC
Working current: 5mA at 1.2V DC/800mA at 5.1V DC
Power consumption of 2.5 watts
Heat dissipation 8.5 BTU/hour
Working temperature 0~60 ° C
Storage temperature -40~85 ° C
Working humidity 5%~95% (no condensation)
Protection level IP20 (installed inside the cabinet)
2G at vibration frequency of 10-500 Hz
Impact work 30G/non work 50G
Size approximately 198 × 98 × 52 mm
Weight approximately 0.55 pounds (0.25 kg)
Electrical isolation 30V DC (continuous), 500V AC (60 second test)
Programming software RSLogix 5000/Studio 5000
Programming language IEC 61131-3 (LD/FBD/ST/SFC)
Firmware version v1.0.0 and above
System architecture and communication capability
┌──────────────────────────────────────────────────────────────┐
│ ControlLogix 1756 chassis │
│ │
│—————————————————————————————
││ 1756-L72 │◄══════════► 1756-IB16 (digital input) ││
││ Controller CPU │ Backplane bus │ 1756-OB16 (digital output) ││
││· 4MB memory ││ 1756-IF16 (analog input) ││
││· 0.98MB I/O ││ 1756-OF8 (analog output) ││
││· Dual Ethernet ││ 1756-EN2T (Ethernet module) ││
││· USB Port ││ 1756-CNBR (ControlNet) ││
│ └──────┬──────┘ └───────────┬──────────────┘ │
│ │ │ │
│ Ethernet/IP │ │
│ ControlNet │ │
│ DeviceNet ▼ │
│ ┌───────────────┐ │
││ On site equipment ││
││ Sensors/actuators ││
││ Servo/Inverter ││
│ └───────────────┘ │
└──────────────────────────────────────────────────────────────┘
Communication protocol support
Purpose of the Agreement
Ethernet/IP upper system communication (SCADA/DCS/HMI)
ControlNet real-time I/O control, motion control
DeviceNet remote I/O, sensor connection
Data Highway Plus old system compatible
SynchLink high-speed synchronous motion control
Remote I/O Remote Distributed I/O (1756 Remote Rack)
core advantage
Advantages Explanation
🎯 High performance processing 32-bit RISC processor, supporting complex control algorithms and multi axis motion control
🔄 Multi axis motion control supports EtherNet/IP integrated motion+SERCOS motion+analog motion
🛡️ Controller redundancy ✅ Support ControlNet redundant pairing, automatic switching for single point of failure
💾 Capacitive energy storage with built-in 1756-ESMCAP capacitor module, no lithium battery required, maintenance free
🔌 hot-plugging ✅ Module online replacement, system does not shut down (RIPP)
📊 SD card storage pre installed 1GB SD card (1784-SD1), expandable up to 2GB (1784-SD2), storing diagnostic data
🔐 The safety version can be selected from 1756-L72S (GuardLogix) and supports SIL 3/Cat.4/PL e
🌡️ Wide temperature working range of 0-60 ° C, suitable for general industrial environments
📦 Multiple racks support up to 10 expansion racks (including remote) and 128 I/O modules
Compatible with chassis and power supply
Compatible with chassis models
10 slot standard chassis 1756-A4, 1756-A4K
17 slot standard chassis 1756-A7, 1756-A7K
10 slot wide chassis 1756-A10, 1756-A10K
17 slot wide chassis 1756-A13, 1756-A13K
10 slot XT chassis 1756-A17, 1756-A17K
Compatible power supply models
Standard power supply 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K
XT power supply 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75K
Typical application scenarios
Industry Applications
🏭 Manufacturing machine tool processing, automatic assembly line, multi axis coordinated motion
⚡ Power turbine control, generator protection, plant power switching
🛢️ Petrochemical reactor safety control, ESD emergency shutdown
🔧 Main drive of metallurgical rolling mill and control of blast furnace fan
💧 Variable frequency speed regulation for large-scale water pumping stations
🏗️ Central air conditioning chiller control and fire linkage in buildings
🤖 Multi robot coordinated control of robots
Comparison of Model Series
Model User Memory I/O Memory Characteristics
1756-L71 2 MB 0.5 MB entry-level
⭐ 1756-L72 4 MB 0.98 MB Standard Type (This product)
1756-L73 8 MB 0.98 MB Large Capacity
1756-L74 16 MB 0.98 MB Extra Large Capacity
1756-L75 32 MB 0.98 MB Flagship Edition
1756-L72S 4 MB+2MB Security 0.98 MB GuardLogix Security Edition
